RM-312 Thermal Imaging Scopes & Infrared Scopes
The 723 series thermal imaging scope has onick RM-312, which can match guns with different ranges. Among the products of the same level, RM has the characteristics of small size, light weight, low power consumption, long recognition distance and high reliability.
Product Details
Product Details
The 723 series thermal imaging scope has onick RM-312, which can match guns with different ranges. Among the products of the same level, RM has the characteristics of small size, light weight, low power consumption, long recognition distance and high reliability. The built-in image transmission module can be wirelessly connected to the head-mounted device, which is convenient for concealed observation and shooting. The operation is simple and reliable, with automatic gun calibration and probability ranging functions.
Features
● Wireless Image Transmission
● IP67 Water And Dust Proof
● Single Roller Operating
● Eye Cup Preventing Light Leaking
● Low Power Consumption
● Auto Zeroing
● Ultra-Far Vision
● High Reliability
Application Fields:
It can record and take pictures, record and restore the scene, and can be used for patrol, law enforcement, search and rescue, drug smuggling, and pursuit of fugitives. It is suitable for special forces such as public security, armed police, and the army to achieve all-weather effective observation of specific areas or targets, and quickly discover, identify, and track targets of concern; it is also suitable for fire protection, electricity, petroleum and other industries to achieve day and night monitoring of specific areas or equipment.
Model Numberonick RM-312Sensor TypeVOx Uncooled Sensor Resolution384288Pixel Pitch12μmNETD40mkFrame Frequency50HzObjective Lens35mmAngle of View7.55.6Continuous Digital Zoom3.4X~13.6XEye Relief48mmDiopter of Eyepiece4Display typeOLEDColor PaletteWhite Hot/Black Hot/Ironbow/Glowbow/Sepia/Red Hot/Green HotDetection Distance1800m(Human, 1.8m)Adjust Accuracy0.12milAdjust Range62.5ⅹ46.6milReticle Type10 typesVideo Resolution1024768Video FormataviBuilt-in Memory32GBWireless ProtocolWi-FiWireless Standard802.11b/g/nFrequency2.4GHzConnection range10mBattery Type18650 Battery2Capacity6400mAhOperating time10hrs.Max. Recoil power on rifles6000JShock resistance on the smooth-bore rifles12Mounting rail typePicatinnyBody MaterialAluminum alloyWeight535g(Mount & Eyeshade excluded)Length150mm(Mount & Eyeshade excluded)Degree of Protection, IP codeIP67Operating Temperature-25℃～+50℃Storage Temperature-40℃～+60℃
